Italian made quality.
Swivel head 45° left & right.
Trigger switch operation.
Quick locking double vice for burr free cutting.
Blade protection clutch, suitable for cutting profile steels or tube where multiple material thicknesses are being cut in 1 pass. The clutch will protect the cutting teeth and material when passing from the thin easier to cut material into the thick harder to cut material.
Incorporated recirculating mechanical coolant system.
Adjustable material stop for repetitive production.
Safety emergency stop switch.
12 months warranty.
Comes complete with blade.
Optional stand available – Part# MC-STAND315
Slow speed (20rpm) model also available designed specifically for cutting stainless-steel. This model is supplied with higher flow, electric coolant pump.
Motor: 3hp Three Phase (415V)
Blade Speed: 2 Speed 40 / 80rpm
Blade Size: 315mm
Blade Bore: 32mm
Weight: 170kg
90° Cutting Capacity: Solid Round: 65mm
Hollow Round: 90mm
Square: 85mm
Rectangle: 120 x 70mm
45° Left & Right Cutting Capacity: Solid Round: 60mm
Hollow Round: 80mm
Square: 70mm
Rectangle: 80 x 70mm
| Weight | 185.0000 kg |
|---|---|
| barcode | 9328042032607 |
| Additional Information |
