The Mitutoyo 7212A Dial Depth Gage has the following specifications:
Range: 0-200mm
Graduation: 0.01mm
Stroke: 10mm
Accuracy: ± 0.015mm
Extension rod: 5pcs.(10, 20, 30, 30, & 100mm)
Base (W x T): 101.6 x 16mm
Flatness: 5um
Features:
ABSOLUTE Digimatic Depth Gage can keep track of the origin point, once set, for the life of the battery. (Series 547)
Wide probing range is available with the supplied extension rod.
Bottom surface of the base is hardened, ground and lapped for highest degree of flatness
Designed with a back-plunger type dial indicator for upward facing readings. (7231A, 7237A, 7238A)
With SPC data output. (Series 547)
| Weight | 0.3100 kg |
|---|---|
| Dimensions | Length 22.86cm x Width 12.7cm x Depth 5.08cm |
| barcode | |
| Additional Information | Digital/Analog: Analog |
