Mitutoyo DIAL INDICATOR 2900SB-70

Product Code: 2900SB-70

$247.05$224.59 Ex. GST

Product Code: 2900SB-70 SKU 2900SB-70 Categories ,

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Bezel clamp and lifting lever (optional) can be attached to either right or left side. They can be easily installed and removed without tools.
No through screw holes on the frame and secure adhesion between the bezel and the crystal as well as the use of an O-ring prevents water or oil penetration.
It eliminates the possibility of reading errors due to miscounting multiple revolutions.

Additional information

Weight 0.1410 kg
barcode
Additional Information

Inch-Metric: Metric
Range: 0.08 mm
Graduation: 0.001 mm
MPE any 1/10 revolution: 2 µm
Mass: 141 g
C: 57 mm
D: 17.7 mm
E: 20 mm
G: 26.2 mm
Stem: 8 mm
Contact point: Carbide tipped, thread: M 2.5 x 0.45 mm
Delivered: with certificate of inspection, limit indicators
One revolution: Yes
Shockproof: Yes
Jeweled bearing: Yes
IP64: Yes
Repeatability: 0.5 µm
Range: 3 µm
Digital/Analog: Analog
H MPE (Hysteresis): 2 µm
R MPE (Repeatability): 1 µm

Brand

Mitutoyo
