Mitutoyo Dial Test Ind B 513-501E

Product Code: 513-501E

$296.08$269.16 Ex. GST

Product Code: 513-501E SKU 513-501E Categories ,

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

The 513-501E pocket-type Dial Test Indicator features a slim profile that allows precision measurements in small, narrow spaces. It has a horizontal face parallel to the axis, and three dovetail mounts allow for horizontal or vertical mounting from the front, top, or back of the indicator. The Indicator’s one-piece movement provides high-impact resistance and better durability, while jeweled bearings deliver high sensitivity and quick response.

It comes with a one-year manufacturer’s warranty.
Shop for 513-501E Dial Test Indicator at MRM Metrology, and save.
Buy 513-501E Test Indicator now for the best price in Canada.

Additional information

Weight 0.0000 kg
barcode
Additional Information

Digital/Analog: Analog
Inch-Metric: Metric
Range: 0.14 mm
Graduation: 0.001 mm
Scale: 0-70-0
MPE any 10 scale divisions: 2 µm
MPE any 1/2 revolution: 3 µm
MPE measuring range: 4 µm
H MPE (Hysteresis): 3 µm
R MPE (Repeatability): 1 µm
Carbide stylus tip ø2 mm No.: 136104
Measuring Force: 0.4 N
Contact Point: Thread M 1.7 x 0.35
Delivered: In a box with stem ø8 mm, stylus ø2 mm
D Ø: 33 mm
L1: 12.1 mm
L2: 8.6 mm
Functions: Basic set

Brand

Mitutoyo
