Mitutoyo Digimatic Gauge 547-316S

Description

The Mitutoyo 547-316S Digital Thickness Gage has the following specifications:

Range: 0-.400″/10mm
Resolution: .0005″/.01mm
Accuracy: +/- .001″
Measuring Force: 1.5N or less
Indicator: Digimatic IDC
Style: Groove Thickness Measurement
The Thickness Gages offer a quick and efficient means of inspection with their convenient grip handle, thumb trigger and spring-loaded spindle. The various models cover a wide range of applications.

FEATURES:

Wide range of applications with various types of measuring faces (on the spindle and anvil).
The digital models incorporate Mitutoyo’s popular ID-C and ID-S Series Digimatic Indicators to provide error-free LCD readings as well as data output for SPC analysis.
