Mitutoyo Digimatic Linear Scale 572-200-20

Description

The Mitutoyo 572-200-20 horizontal single function absolute digimatic scale has the following specifications:

Range: 0-100mm
Resolution: .01mm
Accuracy: .03mm
Model: SD-10DX
The Mitutoyo ABSOLUTE Digimatic Linear Scales are offered in a variety of styles that can all be seen at the bottom of this page.

Horizontal: Single Function, Multi Function, and Multi Function Double Reading
Vertical: Single Function, Multi Function, and Multi Function Double Reading
Features:

The ORIGIN key allows setting of an absolute zero point to be used as reference in subsequent measurements. Once set, the ABS Digimatic Scale Unit is ready to show its true position whenever turned on rather than 0.00″ as with standard models.
The ZERO/ABS key allows the display to be zero-set at any slider position along the beam for incremental comparison measurements. This key will also allow return to the absolute coordinate with a display of the true position from the origin point.
No rack, no pinion, no glass scale. Digimatic Scale Unit is safely embedded in the hardened stainless steel blade.
Horizontal or vertical face according to the scale mounting direction.
Special type that is provided with diameter displaying function is available for lathes.
All units come with two mounting brackets, each located at either end of the scale.
With SPC data output.
Technical Data:

Display: LCD
Length standard: ABSOLUTE electrostatic capacitance type linear encoder
Max. response speed: Unlimited
Battery: SR44 (1 pc.), 938882
Battery life: Approx. 3.5 years under normal use
Function:

Origin-set, Zero-setting, Power on/off, Presetting, Data hold,
Data output, inch/mm conversion (on inch/metric models only),
Alarm: Low voltage, Counting value composition error
