543 Series FEATURES
A conventional Digimatic indicator simply displays a spindle displacement, but the Calculation-Type Digimatic indicator incorporates an internal calculation function in place of spindle displacement. With fixtures, measurements such as feeler, inside diameter and radius of curvature measurement can easily be obtained without the hassle of conversion tables or equivalents.
The Absolute Digimatic indicator performs internal calculations using the formula Ax+B+Cx-1 (assuming spindle displacement as x) while the specified coefficients A, B and, C can be set with respect to the purpose of measurement or dimensions of the fixtures. This unique feature allows you to read your measurements directly, without fumbling for conversions.
Technical Data
Accuracy: Refer to the list of specifications.
Resolution: 0.0001mm – .01mm or .00001” – .05”/0.0001mm – .01mm
Display: LCD
Length standard: ABSOLUTE electrostatic capacitance type linear encoder
Max. response speed: Unlimited
Measuring force: 1.5N or less
Battery: SR44 (1 pc.), 938882
Battery life: Approx. 12 months under normal use
Function
Origin-set/Preset, Zeroset, GO/±NG judgment, Counting direction switching, Power ON/OFF, Data output,inch/mm
conversion (on inch/metric models only)
Alarm: Low voltage, Counting value composition error, Over-flow error, Tolerance limit setting error
| Weight | 0.0000 kg |
|---|---|
| barcode | |
| Additional Information | Resolution: 0.001/0.01 mm |
