Mitutoyo Micrometer B 103-193

Description

Mitutoyo 103-193 Outside Micrometer 16-17″/.001″ Hammertone, baked enamel-finished-frame. Ratchet Stop for exact repetitive readings.

Specifications:
Range:16-17″
Graduation:.001 inch

Weight	2.7150 kg
barcode
Additional Information	Digital/Analog: Analog Delivered: Including box, key, setting standard Inch-Metric: Inch Range: 16 – 17" Graduation: 0,001" Max. Permissible Error (MPE): ±0,00035" Flatness: 0,00004" Parallelism: 0,00024" Measuring face: Carbide-tipped, micro-lap finish Measuring spindle: With spindle lock, ø6,35 mm (≤300 mm) ø 8 mm (>300 mm), spindle pitch 0,5 mm Scale: Thimble and sleeve satin chrome finish, ø21 mm Measuring force: 10 – 15 N Mass: 2715 g
