Mitutoyo Quick Micrometer 293-676-20

Description

293-676-20 Mitutoyo Quickmike IP54 Absolute Digimatic Micrometer: 0-1.2″/30.48mm

The Mitutoyo 293-676-20 Quickmike IP54 Absolute Digimatic Micrometer has the following specifications:

Range: 0-1.2″/30.48mm
Resolution: .00005″/0.001mm
Accuracy: +/- .0001″
The Mitutoyo QuickMike digital micrometer has a fast spindle feed which allows various shapes to be measured quickly. The Mitutoyo Digimatic QuickMike coolant proof digital micrometer feeds the spindle 10mm per thimble rotation, or 20-times faster than standard micrometers. This speed provides quicker measurements on different sized features. The wide measuring range on the Mitutoyo 293-676-20 allows for measuring of different workpieces without sacrificing speed or accuracy.

Features:

The QuickMike provides a speedy spindle feed of 10mm / .4” per thimble rotation compared to the conventional micrometer with .025″/5mm per rotation.
Non-rotating spindle and the new ratchet friction thimble reduces torsion on softer parts being measured
Ratchet thimble allows for easy single-hand use when measuring objects
ABSOLUTE linear scale eliminates the need for setting the origin point every time the micrometer is powered on
Elimination of overspeed errors provides a higher measurement reliability and repeatability
IP54 protection permits use in environments exposed to cutting oil, coolant, dust, etc., for use on most shop floor environments
Available with SPC data output capabilities
Includes a standard bar to set the origin point (for models with 25-55mm / 1-2.2” ranges or larger)
Supplied in fitted plastic case
