Mitutoyo Ring Gage 1.2Mm 177-225

Description

177-225 Mitutoyo Steel Setting Ring – 1.2mm

The Mitutoyo 177-225 Steel Setting Ring has the following specifications:

Nominal Size: 1.2mm
Tolerance Between Nominal and Actual Diameter: +/- .010mm
Uncertainty of Marked Diameter Value: +/- .0015mm
Roundness/Cylindricity: .001mm
Distance from the Side Face (H): 1.6mm
Side of Warranted Calibration Surface (K): 0.8mm
Outside Diameter: 20mm
E Dimension for Type B: N/A
Thickness: 4mm
Type: A
All Mitutoyo Setting Rings can be certified to NIST for an additional charges. Typical turn-around on having a setting ring certified is approximately 4 weeks. If you require the Mitutoyo 177-225 steel setting ring certified prior to shipping out, please reach out to our inside sales team for assistance.

Features:

Used for quick and accurate setting of dial bore gages, Holtest and inside micrometers.
If a setting ring of an optimal size is prepared, it can be used for calibration.
