Mitutoyo VERNIER CALIPER 200mm 536-222

Description

The Mitutoyo 536-222 Vernier Scribing Caliper has the following specifications:

Range: 0-200mm
Graduation: 0.05mm
Accuracy: +/- 0.05mm
Mass: 180 grams
Features:

The carbide-tipped jaws facilitate fine scribing on workpiece.
With depth bar.
With SPC data output. (Series 573)
Supplied in fitted plastic case.
Technical Data

Accuracy: Refer to the list of specifications. (excluding quantizing error for digital models)
Resolution: 0.01mm
Display: LCD
Length standard: ABSOLUTE electrostatic capacitance type linear encoder
Max. response speed: Unlimited
Battery: SR44 (1 pc.), 938882 Battery life: Approx. 3.5 years under normal use
Function

Origin-set, Zero-setting, Power On/Off, Data output, inch/mm conversion (inch/mm models)
Alarm: Low voltage, Counting value composition error
