Powercoil Threaded Inserts 10G x 32 UNF Carbon Steel Thin Wall Solid Insert 5Pk

Description

10G x 32 UNF Carbon Steel Thin Wall Solid Insert 5Pk
Thin Wall UNF Carbon Steel C1215 Loksert Insert.
Loksert keylocking inserts are an easily installed thread assembly that is ideal for replacing damaged or worn threads in virtually any material – ferrous, non-ferrous, and non-metallic.
One piece Loksert inserts are supplied with the dove-tailed locking keys pre-assembled. The pre-positioned keys automatically position the insert at the correct depth below the surface of the parent material.
Lokserts are suitable for repairing and creating threads in a wide range of applications including forgings and castings and are especially suited to situations that experience heavy wear and vibrations – such as mining, construction and earthmoving equipment.
Solid bushing utilising locking keys provides positive mechanical lock against rotation.
High strength and reliability provides maximum pullout strength.
Installed using standard drills and taps.
Simple installation; no special skills required.
Suitable for use in a wide range of parent materials.
Impossible to cross thread during installation.
Simple removal process if required.
No tang to break and remove.
Available in metric sizes and inch sizes.
Available in Miniature, Thinwall, Heavy Duty, Extra Heavy Duty and Solid versions.
Category: Threaded Inserts, Loksert , Loksert Inserts Retail, UNF Thin Wall CARBON STEEL
Pitch (tpi): 32
