PRAMET 125A10R-S19PD09-C

Product Code: 125A10R-S19PD09-C

$1,591.87$1,447.15 Ex. GST

Product Code: 125A10R-S19PD09-C SKU 125A10R-S19PD09-C Categories , ,
PRAMET 125A10R-S19PD09-C

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au
Get advice now

Description

High feed cutter with positve/negative geometry which utilises 10 of PD.X 0905ZE.., PDKT 0905.. or PDMW 0905.. single-sided inserts, cutting diameter 125mm with 19° approach angle and 40mm connection bore according to DIN 8030-A, 63mm protrusion length, through coolant for face milling with a maximum depth of cut of 2.0mm

Additional information

Weight 1.5455 kg
barcode
Additional Information

Description: Value
EAN number: 3603603074071
Product number (SAP): 86025889
Ordering code ANSI: 125A10R-S19PD09-C
Product Line: PENTA HF
Gross weight – grams: 3108.3
Cutting diameter maximum – millimeter (DCX): 125 mm
Cutting diameter – millimeter (DC): 110.3 mm
Connection diameter – millimeter (DCON MS): 40 mm
Counterbore diameter connection bore – millimeter (DCCB): 36 mm
Functional length – millimeter (LF): 63 mm
Radial rake angle (GAMF): -1
Axial rake angle (GAMP): 10
Peripheral effective cutting edge count (ZEFP): 10
Rotational speed maximum (RPMX): 6600
Net weight – grams: 3108.3
Cutter Design: SPD09
Insert index count (NOI): 10
ISO: 125A10R-S19PD09-C

Brand

PRAMET
