PRAMET 200C07R-S90CN10N18 Milling cutters with clamping by screw

Description: Value
EAN number: 3603602955098
Product number (SAP): 86000064
Ordering code ANSI: 200C07R-S90CN10N18
Gross weight – grams: 4050
Milling range CW – Global: 14.0 – 30.5 mm
Cutting diameter – millimeter (DC): 200 mm
Overall length – millimeter (OAL): 50 mm
Connection bore diameter – millimeter (DCB): 40 mm
Hub diameter – millimeter (DHUB): 90 mm
Cutting depth maximum – millimeter (CDX): 52 mm
Cutting Width Range – millimeters (CW): 14.0 ÷ 18.5
Radial rake angle (GAMF): -8
Axial rake angle (GAMP): 4
Face effective cutting edge count (ZEFF): 7
Peripheral effective cutting edge count (ZEFP): 14
Rotational speed maximum (RPMX): 6100
Net weight – grams: 4050
Cutter Design: S90CN(XN)
Insert index count (NOI): 14
ISO: 200C07R-S90CN10N18
