PRAMET 250J09N-S90CN10N18 Milling cutters with clamping by screw

Product Code: 250J09N-S90CN10N18

$5,098.50$4,635.00 Ex. GST

Product Code: 250J09N-S90CN10N18 SKU 250J09N-S90CN10N18 Categories CUTTING TOOLS (HSS & Carbide), H4 - Mill Cutter SCR, Milling

PRAMET 250J09N-S90CN10N18 Milling cutters with clamping by screw

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Disc mill with positve/negative geometry which utilises 18 of CNHQ 1005.. double-sided inserts, cutting diameter 250mm with 90° approach angle and 50mm connection bore according to DIN 8030, for deep slot milling with a width of cut of 14,0 ÷ 18,5mm

Additional information

Weight	4.95 kg
Dimensions
barcode
Additional Information	Description: Value EAN number: 3603602954961 Product number (SAP): 86000051 Ordering code ANSI: 250J09N-S90CN10N18 Gross weight – grams: 5296 Milling range CW – Global: 14.0 – 30.5 mm Cutting diameter – millimeter (DC): 250 mm Overall length – millimeter (OAL): 18 mm Connection bore diameter – millimeter (DCB): 50 mm Hub diameter – millimeter (DHUB): 71 mm Cutting depth maximum – millimeter (CDX): 85 mm Cutting Width Range – millimeters (CW): 14.0 ÷ 18.5 Radial rake angle (GAMF): -8 Axial rake angle (GAMP): 4 Face effective cutting edge count (ZEFF): 9 Peripheral effective cutting edge count (ZEFP): 18 Rotational speed maximum (RPMX): 5500 Net weight – grams: 5296 Cutter Design: S90CN(XN) Insert index count (NOI): 18 ISO: 250J09N-S90CN10N18

Brand

PRAMET
