PRAMET 32E2R080B32-SZD09-C Milling Cutters – HFC

Product Code: 32E2R080B32-SZD09-C

$572.17$520.15 Ex. GST

Product Code: 32E2R080B32-SZD09-C SKU 32E2R080B32-SZD09-C Categories CUTTING TOOLS (HSS & Carbide), H5 - Mill Cutter HFC, Milling

PRAMET 32E2R080B32-SZD09-C Milling Cutters - HFC

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

High feed cutter with positve/negative geometry which utilises 2 of ZDCW 09T3.. single-sided inserts, cutting diameter 32mm with 32mm Weldon shank according to DIN 1835B, 140mm overall length, through coolant for face milling

Additional information

Weight	0.5555 kg
Dimensions	Length 14cm x Width cm x Depth cm
barcode
Additional Information	Description: Value EAN number: 3603602950437 Product number (SAP): 86036884 Ordering code ANSI: 32E2R080B32-SZD09-C Product Line: FEED ZD Gross weight – grams: 756.7 Cutting diameter maximum – millimeter (DCX): 32 mm Cutting diameter – millimeter (DC): 18.7 mm Overall length – millimeter (OAL): 140 mm Connection diameter – millimeter (DCON MS): 32 mm Usable Length – millimeter (LU): 80 mm Radial rake angle (GAMF): -6 Axial rake angle (GAMP): 10 Peripheral effective cutting edge count (ZEFP): 2 Rotational speed maximum (RPMX): 20100 Net weight – grams: 756 Cutter Design: SZD09 Insert index count (NOI): 2 ISO: 32E2R080B32-SZD09-C

Brand

PRAMET
