PRAMET A 05490 300 Adaptors a holders for Copy milling

Product Code: A 05490 300

$1,274.63$1,158.75 Ex. GST

Product Code: A 05490 300 SKU A 05490 300 Categories Boring, CUTTING TOOLS (HSS & Carbide), N2 - Boring

PRAMET A 05490 300 Adaptors a holders for Copy milling

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Integral pocket type boring head size 54 with 90° approach angle and 2 micron adjusting accuracy for finishing within a diamerter range of 63 to 82mm, to hold a TC.. 16T3.. insert for longitudinal boring with and without shoulder

Additional information

Weight	1.2375 kg
barcode
Additional Information	Description: Value EAN number: 3603602959973 Product number (SAP): 86003895 Ordering code ANSI: A 05490 300 Gross weight – grams: 988.6 Connection size code machine side (CZC MS): 54 Cutting diameter minimum – millimeter (DCN): 63 mm Cutting diameter maximum – millimeter (DCX): 82 mm Body diameter maximum – millimeter (BDX): 54 mm Connection diameter – millimeter (DCON MS): 28 mm Functional length – millimeter (LF): 66 mm Bohring related inserts: TC.. 16T3.. Bohring – insert mounting screw: US 0415-T15P Bohring – insert mounting screwdriver: SDR T15P Bohring – adjusting key: HXK 3 Bohring – secure key: HXK 6 Net weight – grams: 983.725 ISO: A05490300

Brand

PRAMET
