PRAMET C6-DDNNN-00065-15 Turning C holders Int & Ext

Product Code: C6-DDNNN-00065-15

$537.04$488.22 Ex. GST

Product Code: C6-DDNNN-00065-15 SKU C6-DDNNN-00065-15 Categories , ,
PRAMET C6-DDNNN-00065-15 Turning C holders Int & Ext

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au
Get advice now

Description

Double clamp turning tool for holding a 55° rhombus negative insert with an inscribed circle diameter of 12.7mm, 6.35mm thick (ISO designation DN.. 1506.. ), neutral hand 62°30′ side cutting with straight shank according to ISO 26623 (Polygon Shank Coupling) size C6, with 65mm protruding length for single and multi-directional copy turning

Additional information

Weight 0.5214 kg
barcode
Additional Information

Description: Value
EAN number: 3603603682719
Product number (SAP): 86036308
Ordering code ANSI: C6-DDNNN-00065-15
Gross weight – grams: 1068.5
Connection diameter – millimeter (DCON MS): 63 mm
Minimum bore diameter Perpendicular – millimeter (DMINP): 190 mm
Functional width – millimeter (WF): 0.5 mm
Functional length – millimeter (LF): 65 mm
Tool cutting edge angle (KAPR): 62.5
Inclination angle (LAMS): -9
Orthogonal rake angle (GAMO): -5
Net weight – grams: 1063
Insert size: 15
ISO: C6-DDNNN-00065-15
