Description: Value
Brand Name: Dormer Pramet
EAN number: 3603604219419
Product number (SAP): 86045689
Size: C6
ISO: C6-SC.04.080
Ordering code ANSI: C6-SC.04.080
Net weight – grams: 3330
Gross weight – grams: 3330
Body diameter – millimeter (BD): 10 mm
Body diameter 2 – millimeters (BD2): 20 mm
Body half taper angle (BHTA): 4.5
Connection diameter workpiece side – millimeter (DCON WS): 4 mm
Connection text machine side (CTMS): C6
Connection text workpiece side (CTWS): M16
Protruding length – millimeter (LPR): 80 mm
|
