PRAMET D 03290 401 Adaptors a holders for Copy milling

Product Code: D 03290 401

$1,359.60$1,236.00 Ex. GST

Product Code: D 03290 401 SKU D 03290 401 Categories Boring, CUTTING TOOLS (HSS & Carbide), N2 - Boring

PRAMET D 03290 401 Adaptors a holders for Copy milling

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Integral pocket type boring head size 32 with 90° approach angle and synchronized adjustment for roughing within a diamerter range of 39 to 50mm, to hold CC.. 0803.. inserts for longitudinal boring with and without shoulder

Additional information

Weight	1.3200 kg
barcode
Additional Information	Description: Value EAN number: 3603602960047 Product number (SAP): 86003902 Ordering code ANSI: D 03290 401 Gross weight – grams: 274.3 Connection size code machine side (CZC MS): 32 Cutting diameter minimum – millimeter (DCN): 39 mm Cutting diameter maximum – millimeter (DCX): 50 mm Body diameter maximum – millimeter (BDX): 32 mm Connection diameter – millimeter (DCON MS): 20 mm Functional length – millimeter (LF): 45 mm Bohring related inserts: CC.. 0803.. Bohring – insert mounting screw: US 0307-T10P Bohring – insert mounting screwdriver: SDR T10P Bohring – adjusting key: HXK 2.5 Bohring – secure key: HXK 4 Net weight – grams: 27.5 ISO: D03290401

Brand

PRAMET
