PRAMET PCLNR 4040 S 19 Turning holders external

Description

Lever lock turning tool for holding a 80° rhombus negative insert with an inscribed circle diameter of 19.05mm, 6.35mm thick (ISO designation CN.. 1906.. ), right hand 95° side and end cutting with off-set shank, 40mm tool height x 40mm width x 250mm long for taper turning, face turning with and without shoulder and longitudinal turning with and without shoulder

Additional information

Weight	0.2981 kg
barcode
Additional Information	Description: Value EAN number: 3603602932655 Product number (SAP): 84003657 Ordering code ANSI: PCLNR 4040 S 19 Gross weight – grams: 3166.7 Shank height – millimeter (H): 40 mm Shank width – millimeter (B): 40 mm Functional height – millimeter (HF): 40 mm Functional width – millimeter (WF): 50 mm Functional length – millimeter (LF): 250 mm Head length – millimeter (LH): 45 mm Inclination angle (LAMS): -6 Orthogonal rake angle (GAMO): -6 Net weight – grams: 3100 Insert size: 19 ISO: PCLNR4040S19

Need Technical Advice?

Description

Additional information

Brand

PRAMET
