PRAMET PCLNR 5050 T 25 Turning holders external

Description

Lever lock turning tool for holding a 80° rhombus negative insert with an inscribed circle diameter of 25.4mm, 9.52mm thick (ISO designation CN.. 2509.. ), right hand 95° side and end cutting with off-set shank, 50mm tool height x 50mm width x 300mm long for taper turning, face turning with and without shoulder and longitudinal turning with and without shoulder

Additional information

Weight	0.4488 kg
barcode
Additional Information	Description: Value EAN number: 3603602925091 Product number (SAP): 84001779 Ordering code ANSI: PCLNR 5050 T 25 Gross weight – grams: 5934 Shank height – millimeter (H): 50 mm Shank width – millimeter (B): 50 mm Functional height – millimeter (HF): 50 mm Functional width – millimeter (WF): 60 mm Functional length – millimeter (LF): 300 mm Head length – millimeter (LH): 50 mm Inclination angle (LAMS): -6 Orthogonal rake angle (GAMO): -6 Net weight – grams: 5900 Insert size: 25 ISO: PCLNR5050T25

Need Technical Advice?

Description

Additional information

Brand

PRAMET
