PRAMET RCMT 1204MOE-FM:T9325 Turning inserts positive

Product Code: RCMT 1204MOE-FM:T9325

$19.71$17.92 Ex. GST

Product Code: RCMT 1204MOE-FM:T9325 SKU RCMT 1204MOE-FM:T9325 Categories , ,

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Single-sided positive turning insert, round with 7° clearance, a diameter of 12mm, 4.76mm thick, indexing accuracy according to ISO-tolerance class-M, chip-breaker FM with rounded cutting edges, in grade T9325, a MT-CVD coated functionally graded WC-Co carbide within ISO ranges P15 -P35 and M10 -M30, for fine to medium machining of steels and stainless-steels

Additional information

Weight 0.0191 kg
barcode
Additional Information

Description: Value
EAN number: 3603602893529
Product number (SAP): 80016050
Ordering code ANSI: RCMT 1204MOE-FM:T9325
Gross weight – grams: 5.267
Insert diameter – millimeter (INSD): 12 mm
Fixing hole diameter – millimeter (D1): 4.4 mm
Insert thickness – millimeter (S): 4.76 mm
Grade: T9325
Insert Clearance Code and Angle: C 7°
Insert Design: RCMT
Insert size: 12
Insert Thickness: 04
Insert Type: T
Chipbreaker manufacturer's designation (CBMD): FM
Insert shape code (SC): R – round
ISO: RCMT1204MOE-FM:T9325

Brand

PRAMET
