PRAMET S06/16 STFCR 06 Adaptors a holders for Copy milling

Product Code: S06/16 STFCR 06

$339.90$309.00 Ex. GST

Product Code: S06/16 STFCR 06 SKU S06/16 STFCR 06 Categories , ,

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Screw clamp boring bar for holding a triangle shape positive insert with an inscribed circle diameter 3.97mm, 1.98mm thick (ISO designation TC.. 06T1.. ), right hand 90° end cutting with off-set shank, steel without coolant hole, 6mm diameter 25mm protrusion length for cone boring and longitudinal boring with and without shoulder

Additional information

Weight 0.3300 kg
barcode
Additional Information

Description: Value
EAN number: 3603602958280
Product number (SAP): 86002114
Ordering code ANSI: S06/16 STFCR 06
Gross weight – grams: 77
Cutting diameter minimum – millimeter (DCN): 8 mm
Cutting diameter maximum – millimeter (DCX): 26 mm
Usable Length – millimeter (LU): 25 mm
Bohring related inserts: TC.. 06T1..
Bohring – insert mounting screw: US 0405-T06P
Bohring – insert mounting screwdriver: SDR T06P
Net weight – grams: 77
ISO: S06/16STFCR06

Brand

PRAMET
