PRAMET SCLCL 1616 H 08 Turning holders external

Product Code: SCLCL 1616 H 08

$162.02$147.29 Ex. GST

Product Code: SCLCL 1616 H 08 SKU SCLCL 1616 H 08 Categories , ,
PRAMET SCLCL 1616 H 08 Turning holders external

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au
Get advice now

Description

Screw clamp turning tool for holding a 80° rhombus positive insert with an inscribed circle diameter of 7.94mm, 3.18mm thick (ISO designation CC.. 0803.. ), left hand 95° side and end cutting with off-set shank, 16mm tool height x 16mm width x 100mm long for chamfering, taper turning, face turning with and without shoulder and longitudinal turning with and without shoulder

Additional information

Weight 0.1573 kg
barcode
Additional Information

Description: Value
EAN number: 3603602962737
Product number (SAP): 86005599
Ordering code ANSI: SCLCL 1616 H 08
Gross weight – grams: 234.5
Shank height – millimeter (H): 16 mm
Shank width – millimeter (B): 16 mm
Functional height – millimeter (HF): 16 mm
Functional width – millimeter (WF): 20 mm
Functional length – millimeter (LF): 100 mm
Head length – millimeter (LH): 15.2 mm
Inclination angle (LAMS): 0
Orthogonal rake angle (GAMO): 0
Net weight – grams: 230
Insert size: 08
ISO: SCLCL1616H08

Brand

PRAMET
