PRAMET SCLCR 10 CA-09

Product Code: SCLCR 10 CA-09

$182.41$165.83 Ex. GST

Product Code: SCLCR 10 CA-09 SKU SCLCR 10 CA-09 Categories , ,
PRAMET SCLCR 10 CA-09

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au
Get advice now

Description

ISO Turning cartridge with screw clamp for holding a 80° rhombus positive insert with an inscribed circle diameter of 9.525mm, 3.97mm thick (ISO designation CC.. 09T3.. ), in accordance with DIN 4985 right hand 95° side and end cutting with off-set shank for chamfering, taper turning, face turning with and without shoulder and longitudinal turning with and without shoulder as well as taper boring and longitudinal boring with and without shoulder

Additional information

Weight 0.1771 kg
barcode
Additional Information

Description: Value
EAN number: 3603602924759
Product number (SAP): 84001702
Ordering code ANSI: SCLCR 10 CA-09
Gross weight – grams: 73.5
Insert size: 09
Minimum bore diameter – millimeter (DMIN): 40 mm
Functional height – millimeter (HF): 10 mm
Functional length – millimeter (LF): 50 mm
Functional width – millimeter (WF): 14 mm
Shank height – millimeter (H): 15 mm
Shank width – millimeter (B): 11 mm
ISO: SCLCR10CA-09

Brand

PRAMET
