PRAMET SCLCR 1212 F 09 Turning holders external

Product Code: SCLCR 1212 F 09

$162.02$147.29 Ex. GST

Product Code: SCLCR 1212 F 09 SKU SCLCR 1212 F 09 Categories , ,
PRAMET SCLCR 1212 F 09 Turning holders external

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au
Get advice now

Description

Screw clamp turning tool for holding a 80° rhombus positive insert with an inscribed circle diameter of 9.525mm, 3.97mm thick (ISO designation CC.. 09T3.. ), right hand 95° side and end cutting with off-set shank, 12mm tool height x 12mm width x 80mm long for chamfering, taper turning, face turning with and without shoulder and longitudinal turning with and without shoulder

Additional information

Weight 0.1573 kg
barcode
Additional Information

Description: Value
EAN number: 3603602921673
Product number (SAP): 84001133
Ordering code ANSI: SCLCR 1212 F 09
Gross weight – grams: 120.3
Shank height – millimeter (H): 12 mm
Shank width – millimeter (B): 12 mm
Functional height – millimeter (HF): 12 mm
Functional width – millimeter (WF): 16 mm
Functional length – millimeter (LF): 80 mm
Head length – millimeter (LH): 16 mm
Inclination angle (LAMS): 0
Orthogonal rake angle (GAMO): 0
Net weight – grams: 118.9
Insert size: 09
ISO: SCLCR1212F09

Brand

PRAMET
