PRAMET SDMX 120508EN-M:M8345 Milling Insert for Sidelock

Product Code: SDMX 120508EN-M:M8345

$30.25$27.50 Ex. GST

Product Code: SDMX 120508EN-M:M8345 SKU SDMX 120508EN-M:M8345 Categories , ,

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Single-sided milling insert SDMX 1205, square for a maximum depth of cut of 12.0mm, with 0.8mm corner radius, an indexing accuracy according to ISO-tolerance class-M and M geometry with rounded cutting edges, M8345 PVD coated WC-Co carbide within ISO-grade ranges M30 -M40 and S20 -S30 for machining of stainless-steel and superalloy with shoulder mills with extended flute J(T)-CSD12X

Additional information

Weight 0.0294 kg
barcode
Additional Information

Description: Value
EAN number: 3603602914361
Product number (SAP): 80023392
Ordering code ANSI: SDMX 120508EN-M:M8345
Gross weight – grams: 10.6
Inscribed circle diameter – millimeter (IC): 12.7 mm
Cutting edge length – millimeter (L): 12.7 mm
Insert thickness – millimeter (S): 5.56 mm
Insert thickness total – millimeter (S1): 6.35 mm
Grade: M8345
Corner radius – millimeter (RE): 0.8 mm
Insert Clearance Code and Angle: D 15°
Insert size: 12
Insert Thickness: 05
Insert Type: X
Chipbreaker manufacturer's designation (CBMD): M
Insert shape code (SC): S – square
ISO: SDMX120508EN-M:M8345

Brand

PRAMET
