Description: Value
EAN number: 3603602869432
Product number (SAP): 80000175
Ordering code ANSI: SNMG 643-M:6630
Gross weight – grams: 29.8
Inscribed circle diameter – millimeter (IC): 19.05 mm
Fixing hole diameter – millimeter (D1): 7.94 mm
Cutting edge length – millimeter (L): 19.05 mm
Insert thickness – millimeter (S): 6.35 mm
Grade: 6630
Corner radius – millimeter (RE): 1.2 mm
Insert Clearance Code and Angle: N 0°
Insert Design: SNMG
Insert size: 19
Insert Thickness: 06
Insert Type: G
Chipbreaker manufacturer's designation (CBMD): M
Insert shape code (SC): S – square
Tool Design: SN
Insert Geometry: Negative
ISO: SNMG190612E-M:6630
|
