Description: Value
EAN number: 3603602869289
Product number (SAP): 80000139
Ordering code ANSI: SNMM 856-HR:6630
Gross weight – grams: 58.579
Inscribed circle diameter – millimeter (IC): 25.4 mm
Fixing hole diameter – millimeter (D1): 9.12 mm
Cutting edge length – millimeter (L): 25.4 mm
Insert thickness – millimeter (S): 7.94 mm
Grade: 6630
Corner radius – millimeter (RE): 2.4 mm
Insert Clearance Code and Angle: N 0°
Insert Design: SNMM
Insert size: 25
Insert Thickness: 07
Insert Type: M
Chipbreaker manufacturer's designation (CBMD): HR
Insert shape code (SC): S – square
Tool Design: SN
Insert Geometry: Negative
ISO: SNMM250724E-HR:6630
|
