PRAMET SPGN 090308:M8340 Milling inserts clamped by wedge

Product Code: SPGN 090308:M8340

$20.74$18.85 Ex. GST

Product Code: SPGN 090308:M8340 SKU SPGN 090308:M8340 Categories , ,

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Single-sided milling insert SPGN 0903 with a plane rake surface, square for a maximum depth of cut of 6.0mm, with 0.8mm corner radius, an indexing accuracy according to ISO-tolerance class-G, M8340 PVD coated fine grained WC-Co carbide within ISO-grade range P25 -P50 for machining of steel with shoulder mills WSP25P

Additional information

Weight 0.0201 kg
barcode
Additional Information

Description: Value
EAN number: 3603602995261
Product number (SAP): 80025100
Ordering code ANSI: SPG 322:M8340
Gross weight – grams: 3.567
Inscribed circle diameter – millimeter (IC): 9.525 mm
Insert thickness – millimeter (S): 3.18 mm
Grade: M8340
Corner radius – millimeter (RE): 0.8 mm
Insert Clearance Code and Angle: P 11°
Insert size: 09
Insert Thickness: 03
Insert Type: N
Chipbreaker manufacturer's designation (CBMD): No chipbreaker
Insert shape code (SC): S – square
ISO: SPGN090308:M8340

Brand

PRAMET
