PRAMET SPUN 250620S:M5326 Milling inserts clamped by wedge

Product Code: SPUN 250620S:M5326

$78.75$71.59 Ex. GST

Product Code: SPUN 250620S:M5326 SKU SPUN 250620S:M5326 Categories , ,

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Single-sided milling insert SPUN 2506 with a plane rake surface, square for a maximum depth of cut of 18.0mm, with 2.0mm corner radius, an indexing accuracy according to ISO-tolerance class-U with rounded cutting edges and facet, M5326 MT-CVD coated WC-Co carbide

Additional information

Weight 0.0765 kg
barcode
Additional Information

Description: Value
EAN number: 3603602996824
Product number (SAP): 80024519
Ordering code ANSI: SPU 845S:M5326
Gross weight – grams: 56.99
Inscribed circle diameter – millimeter (IC): 25.4 mm
Insert thickness – millimeter (S): 6.35 mm
Grade: M5326
Corner radius – millimeter (RE): 2 mm
Insert Clearance Code and Angle: P 11°
Insert size: 25
Insert Thickness: 06
Insert Type: N
Chipbreaker manufacturer's designation (CBMD): No chipbreaker
Insert shape code (SC): S – square
ISO: SPUN250620S:M5326

Brand

PRAMET
