PRAMET SRDCN 1616 H 06 Turning holders external

Description

Screw clamp turning tool for holding a round positive insert with a diameter of 10mm, 3.18mm thick (ISO designation RC.. 1003MO ), neutral hand side and end cutting with straight shank, 20mm tool height x 20mm width x 125mm long for taper turning, single and multi-directional copy turning and longitudinal turning without shoulder

Additional information

Weight	0.1573 kg
barcode
Additional Information	Description: Value EAN number: 3603602921772 Product number (SAP): 84001144 Ordering code ANSI: SRDCN 1616 H 06 Gross weight – grams: 196.4 Shank height – millimeter (H): 16 mm Shank width – millimeter (B): 16 mm Functional height – millimeter (HF): 16 mm Functional width – millimeter (WF): 11 mm Functional length – millimeter (LF): 100 mm Head length – millimeter (LH): 12 mm Inclination angle (LAMS): 0 Orthogonal rake angle (GAMO): 0 Net weight – grams: 195.7 Insert size: 06 ISO: SRDCN1616H06

Need Technical Advice?

Description

Additional information

Brand

PRAMET
