Description: Value
Brand Name: Dormer Pramet
EAN number: 3603603205116
Product number (SAP): 86029331
Size: 30
ISO: VDI.30-HC.08.49
Ordering code ANSI: VDI.30-HC.08.49
Net weight – grams: 1500
Gross weight – grams: 1500
Body diameter – millimeter (BD): 28 mm
Body length – millimeter (LB): 33 mm
Connection diameter – millimeter (DCON MS): 30 mm
Connection diameter workpiece side – millimeter (DCON WS): 8 mm
Connection size Value (CSIZE): 30 – 08
Flange diameter – millimeter (DF): 68 mm
Protruding length – millimeter (LPR): 49 mm
|
