Description: Value
Brand Name: Dormer Pramet
EAN number: 3603603205550
Product number (SAP): 86029375
Size: 40
ISO: VDI.40-DC.16.093.C
Ordering code ANSI: VDI.40-DC.16.093.C
Net weight – grams: 2336
Gross weight – grams: 2336
Body diameter – millimeter (BD): 55 mm
Body length – millimeter (LB): 71 mm
Connection bore diameter minimum – millimeter (DCBN): 3 mm
Connection bore diameter maximum – millimeter (DCBX): 16 mm
Connection diameter – millimeter (DCON MS): 40 mm
Flange diameter – millimeter (DF): 83 mm
Protruding length – millimeter (LPR): 93 mm
|
