Home » Shop » CUTTING TOOLS (HSS & Carbide) » Holding » N1 - Tooling system » PRAMET VDI.40-QTCW.M5.M22 Tooling system

PRAMET VDI.40-QTCW.M5.M22 Tooling system

Product Code: VDI.40-QTCW.M5.M22

$774.97$704.52 Ex. GST

Product Code: VDI.40-QTCW.M5.M22 SKU VDI.40-QTCW.M5.M22 Categories CUTTING TOOLS (HSS & Carbide), Holding, N1 - Tooling system

PRAMET VDI.40-QTCW.M5.M22 Tooling system

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

VDI Quick-Change Tapping Chuck Without Compensation

Additional information

Weight	0.7524 kg
barcode
Additional Information	Description: Value Brand Name: Dormer Pramet EAN number: 3603603205666 Product number (SAP): 86029386 Size: 40 ISO: VDI.40-QTCW.M5.M22 Ordering code ANSI: VDI.40-QTCW.M5.M22 Net weight – grams: 1788.5 Gross weight – grams: 1788.5 Body diameter – millimeter (BD): 52 mm Connection diameter – millimeter (DCON MS): 40 mm Connection diameter workpiece side – millimeter (DCON WS): 31 mm Connection size Value (CSIZE): 2 Connection text range workpiece side (CTWS): M5 – M22 Flange diameter – millimeter (DF): 83 mm Functional length – millimeter (LF): 77 mm

Brand

PRAMET
