Description: Value
Brand Name: Dormer Pramet
EAN number: 3603603205567
Product number (SAP): 86029376
Size: 50
ISO: VDI.50-DC.16.102.C
Ordering code ANSI: VDI.50-DC.16.102.C
Net weight – grams: 3600
Gross weight – grams: 3709
Body diameter – millimeter (BD): 55 mm
Body length – millimeter (LB): 82 mm
Connection bore diameter minimum – millimeter (DCBN): 2.5 mm
Connection bore diameter maximum – millimeter (DCBX): 16 mm
Connection diameter – millimeter (DCON MS): 50 mm
Flange diameter – millimeter (DF): 98 mm
Protruding length – millimeter (LPR): 102 mm
|
