Description: Value
EAN number: 3603602898654
Product number (SAP): 80016633
Ordering code ANSI: WNMM 434-OR:T9325
Gross weight – grams: 8.39
Inscribed circle diameter – millimeter (IC): 12.7 mm
Fixing hole diameter – millimeter (D1): 5.16 mm
Cutting edge length – millimeter (L): 8.7 mm
Insert thickness – millimeter (S): 4.76 mm
Grade: T9325
Corner radius – millimeter (RE): 1.6 mm
Insert Clearance Code and Angle: N 0°
Insert Design: WNMM
Insert size: 08
Insert Thickness: 04
Insert Type: M
Chipbreaker manufacturer's designation (CBMD): OR_
Insert shape code (SC): W – trigon
Tool Design: WN
Insert Geometry: Negative
ISO: WNMM080416E-OR:T9325
|
