Description: Value
EAN number: 3603602882127
Product number (SAP): 80009403
Ordering code ANSI: WNXJ 150935-PM:6630
Gross weight – grams: 69.026
Cutting edge length – millimeter (L): 15 mm
Insert thickness – millimeter (S): 9.52 mm
Depth of cut maximum – millimeter (APMX): 3.5 mm
Major cutting edge angle (KRINS): 15
Inscribed circle diameter – millimeter (IC): 22.225 mm
Insert included angle (EPSR): 75
Wiper edge length – millimeter (BS): 13 mm
Grade: 6630
Cutting depth – minimal – milimeters (ap): 0.8 mm
Cutting depth – maximal – milimeters (ap): 3.5 mm
Feed maximal – millimeter: 9 mm/rev
Insert Clearance Code and Angle: N 0°
Insert Design: WNXJ
Insert size: 15
Insert Thickness: 09
Insert Type: J
Chipbreaker manufacturer's designation (CBMD): PM
Insert shape code (SC): W – trigon
Fixing hole diameter – millimeter (D1): 7.94 mm
ISO: WNXJ150935-PM:6630
|
