Description: Value
EAN number: 3603602882103
Product number (SAP): 80009400
Ordering code ANSI: WNXJ 201380-PR-S01:6630
Gross weight – grams: 170.467
Cutting edge length – millimeter (L): 20 mm
Insert thickness – millimeter (S): 13 mm
Depth of cut maximum – millimeter (APMX): 8 mm
Major cutting edge angle (KRINS): 25
Inscribed circle diameter – millimeter (IC): 31.75 mm
Insert included angle (EPSR): 85
Wiper edge length – millimeter (BS): 15 mm
Grade: 6630
Cutting depth – minimal – milimeters (ap): 1 mm
Cutting depth – maximal – milimeters (ap): 8 mm
Feed maximal – millimeter: 12 mm/rev
Insert Clearance Code and Angle: N 0°
Insert Design: WNXJ
Insert size: 20
Insert Thickness: 13
Insert Type: J
Chipbreaker manufacturer's designation (CBMD): PR-S01
Insert shape code (SC): W – trigon
Fixing hole diameter – millimeter (D1): 9 mm
ISO: WNXJ201380-PR-S01:6630
|
