Description: Value
EAN number: 3603603592742
Product number (SAP): 80031734
Ordering code ANSI: X61 0602-R100 R1:6640
Gross weight – grams: 2.4
Insert width – millimeter (W1): 6.35 mm
Cutting width lower tolerance – millimeter (CWTOLL): -0.03 mm
Cutting width upper tolerance – millimeter (CWTOLU): 0.03 mm
Insert thickness – millimeter (S): 2.33 mm
Grade: 6640
Corner radius – millimeter (RE): 1 mm
Cutting width – millimeter (CW): 2.09 mm
Cutting depth maximum – millimeter (CDX): 2.8 mm
Insert Design: X 61 R-1
Chipbreaker manufacturer's designation (CBMD): With chipbreaker -no designation
Primary Tool Lead Angle: Neutral
ISO: X610602-R100R1:6640
|
