Starrett Dial Test Indicator w/Standard Letter of Certification B708ACZ Dial Test Indicator with SLC

Description

Dial Test Indicator with Dovetail, .010″ Range, 0-5-0 Dial Face, .0001″ Graduations, with Attachments, Case, SLC

Features
Angled head for better reading position
Three dovetail positioning moutns work with existing test indicator accessories
Large 1-3/8″ (35mm) dial diameter
Precision gear-driven design with smooth, jeweled movement
Narrow body for inreach ability
Contact point reverses automatically, always maintaining clockwise hand rotation
Black dial color, .0001″ graduation, .010″ range, 0-5-0 dial reading with 13/16″ (20mm) carbide contact point and .078″ (2mm) ball diameter
Narrow body for inreach ability
Satin chrome finish for durability
Large 1-3/8″ (35mm) dial diameter
Include long carbide contacts 13/16″ (20mm)

Product Specifications
Range (in): .010″
Graduations (in): .0001″
Dial Reading: 0-5-0
Attachments: With Attachments
Contact Point Ball Diameter (in): .078″ (2mm)
Contact Point Length (in): 13/16″
Contact Point Length (mm): 20mm
Dial Color: Black
