Negative 75° Rhombic Ceramic ground inserts without hole for cast iron & hardened steel machining
Additional information
Weight
0.0058 kg
barcode
Additional Information
Applicable Material:, Hard Materials, Grade: AB2010
Application:, Ext 91° App 75° Diamond, Inserts, Min D.O.C.: 0.1 mm
Corner Radius (RE): 0.8 mm
Depth of Cut Maximum (APMX): 2.5 mm
Cutting Edge Length (L): 12.2 mm
Min. Turning Feed (ft(min)): 0.05 mm/rev
Insert Thickness (S): 7.94 mm
Max. Turning Feed (ft(max)): 0.2 mm/rev
Inscribed Circle Diameter (IC): 12.7 mm
Measurement Type: Metric
Cutting Edge Material: Ceramic
Body Material: Carbide
Coating: TiN
Unit: M
