Applicable Material:, Cast Iron, Grade: AS10
Application:, Chamfer & Serration, Facing, Inserts, Maximum Feed per Tooth (fz(max)): 0.25 mm/tooth
Cutting Edge Length (L): 5 mm
Cutting Edge Material: Ceramic
Corner Radius (RE): 1 mm
Minimum Feed per Tooth (fz(min)): 0.13 mm/tooth
Depth of Cut Maximum (APMX): 3 mm
Number of Cutting Edges: 12
Inscribed Circle Diameter (IC): 12.7 mm
Measurement Type: Metric
Insert Thickness (S): 6 mm
Body Material: Carbide
Coating: Si3N4
Unit: M
