Applicable Material:, Cast Iron, Hard Materials, Grade: TT6080
Application:, Chamfer & Serration, Facing, High Feed Milling, Inserts, Maximum Feed per Tooth (fz(max)): 0.2 mm/tooth
Cutting Edge Length (L): 6.1 mm
Cutting Edge Material: Carbide
Corner Radius (RE): 1 mm
Minimum Feed per Tooth (fz(min)): 0.1 mm/tooth
Depth of Cut Maximum (APMX): 5 mm
Measurement Type: Metric
Inscribed Circle Diameter (IC): 19.05 mm
Body Material: Carbide
Insert Thickness (S): 6.35 mm
Unit: M
Coating: AlTiN+TiN
