Applicable Material:, Cast Iron, Hard Materials, Grade: TT6080
Application:, Helical Interpolation, Inserts, Profiling, Rampdown, Maximum Feed per Tooth (fz(max)): 0.14 mm/tooth
Cutting Edge Length (L): 9.5 mm
Cutting Edge Material: Carbide
Corner Radius (RE): 9.5 mm
Minimum Feed per Tooth (fz(min)): 0.07 mm/tooth
Depth of Cut Maximum (APMX): 8 mm
Measurement Type: Metric
Inscribed Circle Diameter (IC): 19 mm
Body Material: Carbide
Insert Thickness (S): 5.3 mm
Unit: M
Coating: AlTiN+TiN
|
