Taegutec RXMX 2006-MR TT9030

Applicable Material:, Steel, Stainless Steel, Super-Alloys / Titanium, Grade: TT9030
Application:, Facing, Helical Interpolation, Inserts, Profiling, Rampdown, Maximum Feed per Tooth (fz(max)): 0.4 mm/tooth
Cutting Edge Length (L): 10 mm
Cutting Edge Material: Carbide
Corner Radius (RE): 10 mm
Minimum Feed per Tooth (fz(min)): 0.1 mm/tooth
Depth of Cut Maximum (APMX): 8 mm
Measurement Type: Metric
Inscribed Circle Diameter (IC): 20 mm
Body Material: Carbide
Insert Thickness (S): 6.35 mm
Unit: M
Coating: TiAlN
