Taegutec S10H SCLCR 03-D05

Product Code: 3606230

$174.46$158.60 Ex. GST

Product Code: 3606230 SKU 3606230 Categories BORING BARS, Carbide, CUTTING TOOLS (HSS & Carbide)

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

TOPMINI screw type boring bars with positive 80° Rhombic inserts for small components machining and 95° approach angle

Weight	0.0600 kg
barcode
Additional Information	Connection Diameter Machine Side (DCONMS): 10 mm Application:, Int 95° App 80° Diamond, Functional Length (LF): 100 mm Body Material: Steel Reduced Body Diameter Length (LDRED): 15 mm Measurement Type: Metric Minimum Bore Diameter (DMIN): 5 mm Unit: M Cutting Direction (HAND): Right Hand
