Screw type boring bars for positive 80° Rhombic inserts of 11° clearance angle with 95° approach angle
Additional information
Weight
0.6100 kg
barcode
Additional Information
Connection Diameter Machine Side (DCONMS): 20 mm
Application:, Int 95° App 80° Diamond, Functional Length (LF): 250 mm
Body Material: Steel
Reduced Body Diameter Length (LDRED): 32 mm
Measurement Type: Metric
Minimum Bore Diameter (DMIN): 25 mm
Unit: M
Cutting Direction (HAND): Right Hand
