Home » Shop » CUTTING TOOLS » COUNTERSINK » INDEXABLE INSERTS » Taegutec SNMG 190608 TT8125B
$48.22$43.84 Ex. GST
Negative Square inserts for medium rough machining of steels & cast irons
Applicable Material:, Steel, Grade: TT8125B Application:, Ext 45° App 90° Square, Ext 45°App Face&Turn 90°Square, Ext 75° App 90° Square, Ext 75° App Face 90° Square, Inserts, Int 75° App 90° Square, Min D.O.C.: 3 mm Corner Radius (RE): 0.8 mm Depth of Cut Maximum (APMX): 8 mm Cutting Edge Length (L): 0 mm Min. Turning Feed (ft(min)): 0.25 mm/rev Insert Thickness (S): 6.35 mm Max. Turning Feed (ft(max)): 0.6 mm/rev Inscribed Circle Diameter (IC): 19.05 mm Measurement Type: Metric Cutting Edge Material: Carbide Body Material: Carbide Coating: TiCN+Al2O3+TiN Unit: M
